Elite Acoustics A1-8

599,00

incl. 19% VAT

Call to the product inquiry
  • 1 high-Z input,
  • GND lift for XLR outputs
  • 1 Class-A microphone and 2 line inputs
  • +48V phantom power
  • 16 selectable digital effects
  • Auxiliary input
  • 8″ woofer & 1″ inch tweeter
  • Monitor section; 3-band EQ, monitor volume,
  • Stereo AUX input with level control
  • Channel 1 direct output (XLR) with GND lift
  • Integrated pole cap
  • Metal housing
  • POTs/sockets on the front panel
  • AC power supply/battery charger
  • Lithium iron phosphate battery (LifePO4)
  • Up to 4 hours playing time (a large capacity battery module is available)
  • Fast charging time
  • Developed and assembled in the USA
  • Speakers: 8″ woofer; 1″ silk dome tweeter
  • 80 watt output
  • Optimized front openings for extended bass response
  • Frequency response 63Hz – 19k Hz
  • Housing: Plywood
  • Amplifier: Ultra-high efficiency class D amplifier
  • EQ control: Low +/- 12 dB at 50 Hz (shelving), Mid +/- 12 dB at 200 Hz – 4 kHz (resonant), High +/- 12 dB at 10 kHz (shelving), Notch
  • +/- 12 dB at 80 Hz – 400 Hz (High-Q resonant)
  • Battery: Built-in lithium iron phosphate (LifePO4) type, rechargeable
  • Typical charging time ~ 5.5 hours
  • Playing time ~ 4 hours (battery modules with higher capacity can be purchased)
  • Power supply: DC 12V, 3000 mA or more
  • Nominal output level (1 kHz): Right channel link out: -10 dBu
  • Main/direct output: +4dBu
  • Channel controls: CH1: EFX send level control, gain control, mute switch
  • CH2/3: Level control & EFX send level
  • EFX effect controls: Dry/Wet knob, Decay/Rate knob
  • 16 different effects: Bright/Dark Cavern, Bright/Dark Hall, Bright/Dark Room, Bright/Dark Plate, Ambience1, Ambience2, Echo,
  • Repeat Echo, Echo/Rev1, Echo/Rev2, Chorus, Flanger
  • Master control: volume control, mono switch, equalizer (low, mid, high control), effect mix, decay/rate, effects
  • Stereo inputs: 1/4″ left/right input sockets
  • Phantom power: +48V
  • Aux input control: Level control
  • Displays: Signal clip, power, +48V, EFX bypass,
  • Connections: CH1: Input sockets (XLR type, 1/4″ TRS phono type), CH2/3: Left/right stereo input (1/4″ TRS phono type)
  • AUX input: input sockets (1/8″ jack)
  • Output: Mix or Direct Out Chan 1 (XLR type)
  • DC in socket Mains switch

Elite Acoustics was founded over 10 years ago in the USA and is now based in Los Angeles, California. The manufacturer is now represented worldwide and develops live electronics such as portable mixers, high-quality preamps, accessories for pedalboards and really good and multifunctional amplifiers for acoustic guitars. We are pleased to be able to offer Elite Acoustics acoustic amplifiers as part of our product range.

Zustand

new

Verstärker-Art

Acoustic guitar

Send product request
